Features:
The product compatible with Alexa and home voice control IOS/Android smart phones app control, can be controlled remotely via Alexa or IFTTT voice and smartphone.
No need for a host, direct connection to wifi, app remote control, timer.
Intelligent scene linking, preset scene execution with one button.
Support Amazon Alexa Echo and the voice control at home.
Support device sharing and multi-person control.
Ultra-low power consumption, energy saving.
It can be used in entertainment venues, parties, weddings, bars, banquet halls, cinemas, entertainment, cars; advertising boards, lighting, decorative TV backlights, computer backlights, etc.
Mobile APP: Smart Life(You can directly scan the QR code on the product to download and install)
Control Range: 20M
Supply Voltage: DC 5-24V
Output: Max. 0-6A/Channel, Total output Max.15A
Connection Method: DC/Wire(Common anode)
Control Mode: WiFi control, voice control
Working Temperature: -20~60℃
Type Description：
1CH: Single Color
2CH: CCT (WW3000K&CW6500K)
3CH: RGB
4CH: RGBW / 4 in 1
5CH: RGB+CCT / 5 in 1(Note: RGB+CCT=RGB WC)
How to use it?
1.Connect this wifi strip light controller to the LED light strip via the 4 pin connector, and also connect to power via the DC port with the power adapter of the light strip.
2.Search "Smart Life" on your app store, or scan the QR code on User Manual to download and install it.
3.Register your Smart Life account.
4.Go to "smart life" app on your phone, click "Direct connect the device control", then you can control your led light strip via your phone.
Note:
- This product should be debugged and installed by qualified personnel.
- This product is not waterproof, so please avoid the sun and rain. If installed outdoors, please use a waterproof box.
- Good heat dissipation conditions will prolong the life of the LED controller. Please install the product in a well-ventilated environment.
- Please check whether the output voltage of the LED power supply used meets the product voltage range requirements.
- The diameter of the wire used must be large enough to load the connected LED lamps, and ensure that the wiring is firm to prevent the wire from overheating or poor contact triggering accidents.
- Before power-on debugging, please ensure that all wiring is correct to avoid damage to the lamp due to incorrect wiring.
Package Including:
1 x LED Controller
