Type/Name Car MP5 Image
Product model:T100C
Voltage 12V
Screen size 7 inches
Product features: 【 selling point 】
1. Bluetooth function (answering/making calls, playing Bluetooth music)
2. Reverse function (additional camera)
3. Video input, supporting video display from recorder
4. Foldable display screen
5. Mobile connectivity (Android phones)
6. FM/AM dual band, supporting RDS function
7. High definition capacitive screen
8. Mobile charging function
Main functions of the product:
1. Radio (FM/AM dual band)
2. Card reading, USB flash drive reading (audio/video/image playback)
3. AUX function
4. Bluetooth function
5. Reverse function (with additional camera)
6. Original car steering wheel learning function
7. Mobile connectivity (Android phones)
8. Supports RDS functionality
9. Mobile charging function
System parameters
System WIN CE
Decoding chip full intelligence C200S
Screen size 7 inches
Touch screen type capacitive screen
Screen resolution 1024 * 600
Button light blue light
The time system is 12 hour/24 hour adjustable
Standby time not supported
Mobile internet support (Android phones)
Mobile charging support
Radio Band FM1/FM2/FM3/AM1/AM2
Radio chip SI4731
Does it support RDS support
Is OBD supported? Not supported
Multilingual Chinese/English/Spain/Portugal/Russia/Italy/Germany/France/Poland/Türkiye/Czech/Hebrew/Arabic
Video output 2-way video output (does not support dual screen display)
Reverse video input support
Reverse detection method: Reverse detection line connected to reverse lamp power supply
Is TV supported? Not supported
Bluetooth connection password PIN: 0000
Car logo setting not supported
Brake reminder function support
Bluetooth version 4.0
Power amplifier chip TDA7388
Radio frequency FM87.5~108.0MHz AM522~1620KHz
SD card slot TF memory card
GPS card slot not available
Remote control Xiaomi remote control
USB interface and two USB 2.0 interfaces, 1: USB drive playback. 2: Mobile phone charging
Reset the button and use Reset to reset the small hole. Use a small sharp object to poke into the small hole and touch the button to reset the system
Original car steering wheel control support
RCA terminal introduction: "Two audio outputs (OUT-L, OUT-R), two video outputs (V-OUT1, V-OUT2),
1 video input (CVBS IN), 1 reverse input (CAM IN)“
Front AUX audio input support
Volume knob support
Supported audio formats MP3/WMA/WAV/APE/FLAC
Supported video formats RM/RMVB/AVI/MP4/MKV/3GP (resolution within 720P)
Supported image formats JPG
Packing parameters
Unit weight (gross weight) 1704.5g Unit weight (net weight) 1445.7g
Single item size (color box) 210 * 95 * 240MM Single item with camera (gross weight) 1831.6g
Single product host size 188 * 58 * 175mm
Full container quantity Full container size
Gross weight of the entire box Net weight of the entire box
Product List
1. Host
2. power cord
3. Remote control
4. Manual
5. Dismantling key
tips:
T100C:has carply
T100:no carplay
